The 4th generation Robox is a modular and economical palletizer offered in over 20 pre-configured floor plans. With its compact footprint, the Robox easily adapts to changing layouts and utilizes OptiStak, giving you the freedom to set new or adjust pallet patterns directly from the HMI without new programming needed. The new module layout system also breaks down for easy pallet shipping. Go from power-up to production in a short amount of time with Schneider Robox at the end of your line.



robox_logo






ROBOX FEATURES

  • Customized end-of-arm tooling (EOAT) specifically designed to handle your product(s)
      ο Available multiple products per pick enables a high throughput
  • Locking guard doors
  • Zoned 24 volt product conveyor
      ο Available in perpendicular and in-line configurations
  • Modular design allows many configurations
      ο 1-in-1-out with four configurations and provides options, such as sheet magazines and over/under conveyor
      ο 1-in-2-out configuration has up to two layer sheet magazines as options but does not offer the over/under conveyor
  • OptiStak means no programming is required. The HMI is the only control necessary to set new pallet patterns or make adjustments for new products
  • Ships via pallets for easy placement

PALLET GENERATION SOFTWARE (OPTISTAK)

OptiStak is a seamless and simple palletizing software that meets the production requirements of virtually any industry or product. With OptiStak, your operators can change patterns on the fly, optimize pallet configurations quickly, and avoid changeover delays—directly from the HMI.

OptiStak is an integrated software with the Schneider modular palletizers.

Learn More »



SEE THE ROBOX IN ACTION

REQUEST A QUOTE

Contact Us Here
Find Out More

SPECIFICATIONS

Product Types
Cases
Pallet Types
GMA, CHEP
Maximum Case Weight
50 lbs.
Unit Load Height
84"
Minimum Case Dimensions
6.5" x 4.5" x 3"
Maximum Case DImensions
22" x 16" x 16"
End-Of-Arm Tooling (EOAT)
Vacuum, Mechanical tool pending
Controller
Rockwell Automation Compact GuardLogix
Power Requirements
480 Volt, 3 Phase, 60Hz, 50 Amps
Construction
Standard: Painted, carbon steel
Visual Display
Rockwell Automation panel PC
Dimensions (W x L x H)
106" x 90.5" x 116" 1-In-1-Out Short - floor load
133" x 90.5" x 116" 1-In-1-Out Extended - floor & over/under
106" x 139" x 116"  1-In-2-Out Double Short - floor load
133" x 139" x 139"  1-In-2-Out Double Extended - floor load
Safety
Meets ANSI/PMMI B155.1 Safety Standards

INTEGRATIONS

  • Product and pallet labeling
  • Conveyor, shuttle cart, and automated guided cart
  • Pallet and layer sheet dispenser or magazine
  • Over/Under conveyor
